Some advice from LandGlass about what to do if the radius is smaller than the standard template during the glass tempering process.
- When processing curved tempered glass, a standard template will be used to adjust the shape of the lower bending chiller to meet the curvature of the standard template. Any deviation in the adjusting process may lead to a smaller radius of the bent glass. In this case, curvature should be re-adjusted using the template.
- When the curvature of the lower bending chiller of the tempering furnace is well adjusted, the bending button should be pressed manually to make the rollers of the lower chiller fit completely with the template. Write down the height of the arc provided by the computer system and input the value into the parameters for processing such glass. If the value set for the arc height is too large, the radius of the glass under process will be small. The set value should be reduced appropriately.
- When the glass enters the bending chiller for the quenching process, excessively high air pressure of the lower chiller will cause a smaller radius of the bent glass. In this case, the valve of the air distribution box should be adjusted to reduce the pressure of the lower chiller.
- If the temperature of the upper surface of the glass is too high when leaving the furnace, the interaction of stress between the inner and outer layers of the glass will lead to an increase of shrinkage on the upper surface of the glass in the chiller, causing an increase in the upward bending of the glass and a smaller radius of the bent glass. In this case, the upper heating temperature of the furnace should be appropriately decreased to reduce the exit temperature of upper glass surface.
