G Series Double Lite Edition – Main features
No further glass registra- tion, with a faster ROI.
tions are necessary before The machine is made up General
the printing process. of an entry/squaring con- Printing repeatability <+/- 0.08 mm
veyor, a printing body and Printing head
G SERIES DOUBLE an exit synchronized con- Constant pressure during printing
LITE EDITION
veyor. The purpose of the Independent speed adjustment
The G series special edi- pre-centring conveyor is to Anti-drop system
tion DLE (Double Lite perform the correct align- Squeegee run length auto learning
Screen
Edition) for double glass ment of the two glasses be-
Screen extraction without loss of register
printing has been engi- fore they are moved to the
Automatic peel-off adjustment
neered with the aim to have centring device.
the maximum flexibility in
An outstanding
a single printing line. Two
centring system
small glasses (sidelites or
vents) or one single big Its outstanding centring
glass (backlite, windshield system has 18 axes that
or sunroof) can be printed enable to perfectly cen-
on one printing machine, tre all types of glass, even
resulting in important sav- those with extreme shapes.
ings in terms of industrial This automation allows a
space and cost optimiza- very fast setup of the ma-
Double glass handling
