adjustment. There are manual set values can be displayed on the Compatible with SORG burners and
spindles for adjusting the burn- SCADA monitor. It is also pos- those from other manufacturers
er angles and the set values sible to use the SCADA system The new type WSH and WSA
can be read directly from the to change the vertical adjustment burner holders are compatible
scales marked on the burner from the control room. For the with the SORG burners NL4,
holder. The sealing plate is first time this enables the opera- NL5, SDB231 2F and SDB221
fixed to the burner holder, so tor to adjust the burner whilst 2F. In principle they are also
no additional fastening of the observing the influence on the suitable for use with other
plate is necessary and the risk flame pattern monitored by the SORG burners or even burners
of displacement during burn- furnace camera. from different manufacturers.
er adjustment is eliminated. The activator moves at 1mm/s, However, in each case the possi-
Attachment of the holder to the which allows fine adjustment of bility must be checked by SORG
existing furnace steel structure the burner angle. In practical engineers. O
is straightforward. terms this means that the actua-
tor adjusts the burner angle by
TWO DIFFERENT VERSIONS – 0.1° in two seconds. The actuator
WSH AND WSA is suitable for temperatures up
Two versions of the burner to 80°C, and additional cooling
holder are available: from the furnace cooling air sys-
1. Type WSH with manual tem can be added if required.
adjustment of both angles. Holder type WSH can be
This is the basic version. The upgraded easily to type WSA at
angles set can be read on the any time.
scales. For type WSA there is also SORG (NIKOLAUS)
2. Type WSA with manual adjust- the option of installing a local GmbH & CO.
ment of the horizontal angle operating unit at the burners.
Stoltestrasse 23
(as with the WSH model), but Burner adjustment can then also D-97816 Lohr am Main - Germany
with motorized adjustment of be monitored directly in situ, in Tel.: +49-9352-507-0
the vertical angle by means of addition to adjustments carried Fax: +49-9352-507234
an actuator. out from the control room. The E-mail: nsorg@sorg.de
The actuator provides an out- set angles are shown locally on a www.sorg.de
put signal that can be connected display and also on the SCADA
to the SCADA system so that the system.
