        Company update






































            tics of glass containers, on sam-
            ple basis.
               The inspection line, installed in
            the cold end, near the glass con-
            tainers production line, includes
            products from three different
            companies: Marposs, Somex and
            Vertech.
               The inspection line is made
            up of:
            t  .BSQPTT  7JTJ2VJDLÎ   nFYJCMF
               gauging machine with special
               conveying system;
            t  7FSUFDI  4*-Î   QSPEVDUJPO
               monitoring software;
            t  4PNFY  3PCVSTUÎ   BVUPNBUJD
               glass bottle pressure tester.
               The inspection line includes
            four input conveyors (a, b, c, d),   WFZPS  */  JOTJEF UIF 7JTJ2VJDLÎ   The internal profile measure-
            to house four sets of different   machine where they are meas-     ment is very accurate thanks to
            articles. Glass containers to be   ured with cameras (1), as far as   the integration of a linear encod-
            measured are manually loaded on   external parameter are concerned   er, fully synchronized with the
            the conveyors.                    (height, verticality, parallelism,   bore gauge readings. This feature
               Containers present on the con-  diameters on body neck and fin-  is based on Marposs proprietary
            veyors are delivered, one set at a   ish, long/short side and diagonals   technology (DigiCrown™ net-
            time, in a sequence programmed    on non-round containers, angles,   work system).
            PO  7FSUFDI  4*-Î   UP  B  TJOHMF   radii and many others), and      After being measured on the
            JOQVU DPOWFZPS  */  FOUFSJOH UIF   subsequently with a bore gauge   VisiQuick™ machine, containers
            VisiQuick™ machine.               (2), measuring mouth internal    are delivered to a single output
               A pick & place device brings   diameter, at different depths, and   conveyor (OUT) that can convey
            the containers from the input con-  internal profile.               them alternatively to the Somex
