a quality control system   out  continuous  turning  ferent large sizes and thick-
                                     with output cursor which   of the glass sheets, mov-  nesses. Thanks to a double
                                     shows the results on the   ing them from left to right,   transport belt, the first glass
                                     glass sheet. The section is   and is equipped with an   sheet can be raised as re-
                                     equipped with LED lights   air cushion on both sides,   quired by the offset meas-
                                     to facilitate possible non-  to maintain the glass being   urement.  The  coupling
                                     conformity, with an inter-  processed separate from the   press also has a lower pat-
                                     nal semi-moveable pedal.   structure of the machine. In   ented glass positioning de-
                                     Considering  that  with  the lower part, there is a belt   vice, thus guaranteeing high
                                     stepped glass the frame   that automatically positions   precision and reliability dur-
                                     is installed on the larger   the glass sheet as per its   ing glass filling operations.
                                     glass, the support has a   thickness. The glass turning   The gas insertion slot is
                                     reference bar with a glass   section can tilt more than 6°,   standardized for the whole
                                     stopper, with horizontal   even reaching 15°. A safety   surface of the machine, ex-
                                     passing up to 1 metre. The   system guarantees that the   ploiting the 24 + 32 suc-
                                     smaller reference for spac-  glass sheets do not move or   tion cups, which enable the
                                     er positioning is automatic.   exit during turning.  transport belt to be in the
                                     Moreover, there is also the                        correct position for the gas
                                                              Gas filling coupling press
                                     possibility of steps up to                         filling operations: straight-
                                     250 millimetres vertical to   The coupling press of the   ening the glass sheet to
                                     the base.                Forel “No-Limits” Jumbo   ensure that the gas to allow
                                                              Line created for Tvitec of-  the gas to penetrate cor-
                                     Glass turning section
                                                              fers high performance and   rectly from the bottom, the
                                     The glass turning section   is able to easily process   suction cups guarantee the
                                     has been designed to carry   stepped glass sheets of dif-  correct exit of the air from
